先簡單的介紹下CAShapeLayer
1、CAShapeLayer繼承自CALayer,可使用CALayer的所有屬性
2、CAShapeLayer需要和貝塞爾曲線配合使用才有意義。
Shape:形狀
貝塞爾曲線可以為其提供形狀,而單獨使用CAShapeLayer是沒有任何意義的。
3、使用CAShapeLayer與貝塞爾曲線可以實現不在view的DrawRect方法中畫出一些想要的圖形
關于CAShapeLayer和DrawRect的比較
DrawRect:DrawRect屬于CoreGraphic框架,占用CPU,消耗性能大
CAShapeLayer:CAShapeLayer屬于CoreAnimation框架,通過GPU來渲染圖形,節省性能。動畫渲染直接提交給手機GPU,不消耗內存
貝塞爾曲線與CAShapeLayer的關系
1、CAShapeLayer中shape代表形狀的意思,所以需要形狀才能生效
2、貝塞爾曲線可以創建基于矢量的路徑
3、貝塞爾曲線給CAShapeLayer提供路徑,CAShapeLayer在提供的路徑中進行渲染。路徑會閉環,所以繪制出了Shape
4、用于CAShapeLayer的貝塞爾曲線作為Path,其path是一個首尾相接的閉環的曲線,即使該貝塞爾曲線不是一個閉環的曲線
說完了簡介們來看一下如何創建一個簡單的CAShapeLayer
CAShapeLayer *shapeLayer = [CAShapeLayer layer]; shapeLayer.frame = CGRectMake(100, 100, 100, 100); shapeLayer.backgroundColor = [UIColor yellowColor].CGColor; [self.view.layer addSublayer:shapeLayer];
配合路徑使用
UIBezierPath *path = [UIBezierPath bezierPathWithArcCenter:CGPointMake(50, 50) radius:50 startAngle:0 endAngle:M_PI * 2 clockwise:YES]; shapeLayer.path = path.CGPath;
填充路徑顏色: strokeColor
shapeLayer.strokeColor = [UIColor greenColor].CGColor;
填充路徑內顏色:fillColor
shapeLayer.fillColor = [UIColor lightGrayColor].CGColor;
將背景顏色和路徑內顏色設置為透明
shapeLayer.backgroundColor = [UIColor clearColor].CGColor; shapeLayer.fillColor = [UIColor clearColor].CGColor;
如果要實現彩色的精度條,我選擇利用蒙版mask
先讓shapeLayer 與 路徑 '分離'
CAShapeLayer *layer = [CAShapeLayer layer]; UIBezierPath *path = [UIBezierPath bezierPathWithArcCenter:CGPointMake(200, 200) radius:200 startAngle:0 endAngle:M_PI * 2 clockwise:YES]; layer.path = path.CGPath; layer.lineWidth = 3; layer.fillColor = [UIColor clearColor].CGColor; layer.strokeColor = [UIColor blueColor].CGColor; layer.frame = CGRectMake(0, 0, 50, 50); layer.backgroundColor = [UIColor yellowColor].CGColor; [self.view.layer addSublayer:layer];
再創建一個漸變圖層做成圓形狀
CAGradientLayer *gradientLayer = [CAGradientLayer layer]; gradientLayer.frame = CGRectMake(0, self.view.center.y - 200, 400, 400); gradientLayer.startPoint = CGPointMake(0.5, 0); gradientLayer.endPoint = CGPointMake(0.5, 1); NSMutableArray *colors = [NSMutableArray array]; for (int hue = 0; hue lt;= 360; hue ) { UIColor *color = [UIColor colorWithHue:hue / 360.0 saturation:1.0 brightness:1.0 alpha:1]; [colors addObject:(id)color.CGColor]; } gradientLayer.colors = colors; [self.view.layer addSublayer:gradientLayer]; gradientLayer.cornerRadius = 200;
如果不了解漸變圖層可以查閱相關資料
http://www.jianshu.com/writer#/notebooks/5179914/notes/6190732圓形漸變圖層.png
'套上'蒙版即可搞定
gradientLayer.mask = layer;
如果想實現動畫效果也是可以滴
// 動畫 layer.speed = 0.1; CABasicAnimation *animation = [CABasicAnimation animationWithKeyPath:@quot;strokeEndquot;]; animation.duration = 1; animation.fromValue = http://www.tuicool.com/articles/@0; animation.toValue = @1; [layer addAnimation:animation forKey:@quot;:joy:好棒#55358;#56599;quot;];
除了圓形還可以是圓弧只要修改strokeStart 和 strokeEnd即可
// 動畫 layer.strokeStart = 0; layer.strokeEnd = 0.8; layer.speed = 0.1; CABasicAnimation *animation = [CABasicAnimation animationWithKeyPath:@quot;strokeEndquot;]; animation.duration = 1; animation.fromValue = http://www.tuicool.com/articles/@0; animation.toValue = @0.8; [layer addAnimation:animation forKey:@quot;:joy:好棒#55358;#56599;quot;];
