1 - 引言
之前我們學習了神經網路的理論知識，現在我們要自己搭建一個結構為如下圖所示的神經網路，對Cifar-10資料集進行分類
前向傳播比較簡單，就不在贅述
反向傳播需要注意的是，softmax的反向傳播與之前寫的softmax程式碼一樣。神經網路內部的反向傳播權重偏導就是前面的係數，偏置的導為1，所以就是傳播輸入的累加和，ReLU函式在反向傳播時，小於零的均為0，大於零的不變
根據求導過程可以寫出相應的程式碼，以下是具體步驟
2 - 具體步驟
構建函式，計算loss和gradients
def loss(self, X, y=None, reg=0.0): """ 計算兩層全連線神經網路的loss和gradients 輸入： - X ：輸入維數為（N,D） - y : 輸入維數為（N，） - reg : 正則化強度 返回： 如果y是None,返回維數為(N,C)的分數矩陣 如果y 不是None ,則返回一個元組： - loss : float 型別，資料損失和正則化損失 - grads : 一個字典型別，儲存W1，W2，b1,b2的梯度 """ # Unpack variables from the params dictionary W1, b1 = self.params['W1'], self.params['b1'] W2, b2 = self.params['W2'], self.params['b2'] N, D = X.shape # Compute the forward pass scores = None # 完成前向傳播，並且計算loss # Store the result in the scores variable, which should be an array of # # shape (N, C). # h1 = np.maximum(0, np.dot(X, W1) + b1) h2 = np.dot(h1, W2) + b2 scores = h2 # If the targets are not given then jump out, we're done if y is None: return scores # Compute the loss loss = None exp_class_score = np.exp(scores) exp_correct_class_score = exp_class_score[np.arange(N), y] loss = -np.log(exp_correct_class_score / np.sum(exp_class_score, axis=1)) loss = sum(loss) / N loss += reg * (np.sum(W2 ** 2) + np.sum(W1 ** 2)) # Backward pass: compute gradients grads = {} #計算反向傳播，將權重和偏置量的梯度儲存在params字典中 # layer2 dh2 = exp_class_score / np.sum(exp_class_score, axis=1, keepdims=True) dh2[np.arange(N), y] -= 1 dh2 /= N dW2 = np.dot(h1.T, dh2) dW2 += 2 * reg * W2 db2 = np.sum(dh2, axis=0) # layer1 dh1 = np.dot(dh2, W2.T) dW1X_b1 = dh1 dW1X_b1[h1 <= 0] = 0 dW1 = np.dot(X.T, dW1X_b1) dW1 += 2 * reg * W1 db1 = np.sum(dW1X_b1, axis=0) grads['W2'] = dW2 grads['b2'] = db2 grads['W1'] = dW1 grads['b1'] = db1 return loss, grads
完成前向和反向傳播後，其實最核心的部分就在這裡，然後我們繼續實現神經網路的訓練和預測
def train(self, X, y, X_val, y_val, learning_rate=1e-3, learning_rate_decay=0.95, reg=5e-6, num_iters=100, batch_size=200, verbose=False): """ 使用stochastic gradient descent (SGD)來訓練神經網路 輸入： -X ：一個numpy陣列，維數（N，D） -y ：一個numpy陣列，維數（N，） - X_val : 一個numpy陣列，維數（N_val, D） - y_val : 一個numpy陣列，維數（N_val,） - learning_rate : 學習速率 - learning_rate_decay : 學習速率衰減 - reg : 正則化強度 - num_iters : 訓練次數 - batch_size : 一批訓練的數量 - verbose : boolean；標誌量，是否列印訓練過程 """ num_train = X.shape[0] iterations_per_epoch = max(num_train / batch_size, 1) # Use SGD to optimize the parameters in self.model loss_history = [] train_acc_history = [] val_acc_history = [] for it in range(num_iters): X_batch = None y_batch = None # them in X_batch and y_batch respectively. randomIndex = np.random.choice(len(X), batch_size, replace=True) X_batch = X[randomIndex] y_batch = y[randomIndex] # Compute loss and gradients using the current minibatch loss, grads = self.loss(X_batch, y=y_batch, reg=reg) loss_history.append(loss) # Use the gradients in the grads dictionary to update the for param_name in self.params: self.params[param_name] += -learning_rate * grads[param_name] if verbose and it % 1000 == 0: print('iteration %d / %d: loss %f' % (it, num_iters, loss)) # Every epoch, check train and val accuracy and decay learning rate. if it % iterations_per_epoch == 0: # Check accuracy train_acc = (self.predict(X_batch) == y_batch).mean() val_acc = (self.predict(X_val) == y_val).mean() train_acc_history.append(train_acc) val_acc_history.append(val_acc) # Decay learning rate learning_rate *= learning_rate_decay return { 'loss_history': loss_history, 'train_acc_history': train_acc_history, 'val_acc_history': val_acc_history, } def predict(self, X): """ 使用這個網路模型的訓練權重來預測資料 輸入： - X : 一個numpy陣列，維數（N，D） 返回： - y_pred : 一個numpy陣列，維數(N, ) """ y_pred = None W1, b1 = self.params['W1'], self.params['b1'] W2, b2 = self.params['W2'], self.params['b2'] h1 = np.maximum(0, np.dot(X, W1) + b1) h2 = np.dot(h1, W2) + b2 scores = h2 y_pred = np.argmax(scores, axis=1) return y_pred
可以簡單的構造一個輸入資料來測試一下這個神經網路
from cs231n.classifiers.neural_net import TwoLayerNet input_size = 4 hidden_size = 10 num_classes = 3 num_inputs = 5 def init_toy_model(): np.random.seed(0) return TwoLayerNet(input_size, hidden_size, num_classes, std=1e-1) def init_toy_data(): np.random.seed(1) X = 10 * np.random.randn(num_inputs, input_size) y = np.array([0, 1, 2, 2, 1]) return X, y net = init_toy_model() X, y = init_toy_data() net = init_toy_model() stats = net.train(X, y, X, y, learning_rate=1e-1, reg=1e-5, num_iters=100, verbose=False) print('Final training loss: ', stats['loss_history'][-1]) # plot the loss history plt.plot(stats['loss_history']) plt.xlabel('iteration') plt.ylabel('training loss') plt.title('Training Loss history') plt.show()
Final training loss: 0.01716153641191769
可以看到我們的網路有很好的效果，現在，就可以載入Cifar-10資料集來進行圖片的分類了。
import numpy as np
import matplotlib.pyplot as plt
from cs231n.classifiers.neural_net import TwoLayerNet
from cs231n.data_utils import load_CIFAR10
def get_CIFAR10_data(num_training=49000, num_validation=1000, num_test=1000):
"""
將我們之前載入資料的程式碼封裝成函式
"""
# Load the raw CIFAR-10 data
cifar10_dir = 'cs231n/datasets/cifar-10-batches-py'
X_train, y_train, X_test, y_test = load_CIFAR10(cifar10_dir)
# Subsample the data
mask = range(num_training, num_training + num_validation)
X_val = X_train[mask]
y_val = y_train[mask]
mask = range(num_training)
X_train = X_train[mask]
y_train = y_train[mask]
mask = range(num_test)
X_test = X_test[mask]
y_test = y_test[mask]
# Normalize the data: subtract the mean image
mean_image = np.mean(X_train, axis=0)
X_train -= mean_image
X_val -= mean_image
X_test -= mean_image
# Reshape data to rows
X_train = X_train.reshape(num_training, -1)
X_val = X_val.reshape(num_validation, -1)
X_test = X_test.reshape(num_test, -1)
return X_train, y_train, X_val, y_val, X_test, y_test
# 載入資料集
X_train, y_train, X_val, y_val, X_test, y_test = get_CIFAR10_data()
input_size = 32 * 32 * 3
hidden_size = 50
num_classes = 10
net = TwoLayerNet(input_size, hidden_size, num_classes)
# Train the network
stats = net.train(X_train, y_train, X_val, y_val,
num_iters=3000, batch_size=200,
learning_rate=1e-4, learning_rate_decay=0.95,
reg=0.5, verbose=True)
# Predict on the validation set
val_acc = (net.predict(X_val) == y_val).mean()
print('Validation accuracy: ', val_acc)
# Plot the loss function and train / validation accuracies
plt.subplot(2, 1, 1)
plt.plot(stats['loss_history'])
plt.title('Loss history')
plt.ylabel('Loss')
plt.subplot(2, 1, 2)
plt.plot(stats['train_acc_history'], label='train')
plt.plot(stats['val_acc_history'], label='val')
plt.xlabel('Epoch')
plt.ylabel('Clasification accuracy')
plt.show()
iteration 0 / 3000: loss 2.303370
iteration 1000 / 3000: loss 2.050751
iteration 2000 / 3000: loss 1.816003
Validation accuracy: 0.39
可以看到使用初始設定的超引數準確率只有39%，所以我們接下來需要使用交叉驗證來尋找最適合的超引數。
# 載入資料集
X_train, y_train, X_val, y_val, X_test, y_test = get_CIFAR10_data()
input_size = 32 * 32 * 3
num_classes = 10
best_net = None # store the best model into this
hidden_size = [75, 100, 125]
results = {}
best_val_acc = 0
best_net = None
learning_rates = np.array([0.7, 0.8, 0.9, 1, 1.1]) * 1e-3
regularization_strengths = [0.75, 1, 1.25]
print('running')
for hs in hidden_size:
for lr in learning_rates:
for reg in regularization_strengths:
print(',')
net = TwoLayerNet(input_size, hs, num_classes)
# Train the network
stats = net.train(X_train, y_train, X_val, y_val,
num_iters=1500, batch_size=200,
learning_rate=lr, learning_rate_decay=0.95,
reg=reg, verbose=False)
val_acc = (net.predict(X_val) == y_val).mean()
if val_acc > best_val_acc:
best_val_acc = val_acc
best_net = net
results[(hs, lr, reg)] = val_acc
print()
print("finshed")
# Print out results.
for hs, lr, reg in sorted(results):
val_acc = results[(hs, lr, reg)]
print('hs %d lr %e reg %e val accuracy: %f' % (hs, lr, reg, val_acc))
print('best validation accuracy achieved during cross-validation: %f' % best_val_acc)
輸出結果如下，經過交叉驗證之後準確率提升到了49%，接近50%
hs 75 lr 7.000000e-04 reg 7.500000e-01 val accuracy: 0.465000
hs 75 lr 7.000000e-04 reg 1.000000e+00 val accuracy: 0.466000
hs 75 lr 7.000000e-04 reg 1.250000e+00 val accuracy: 0.451000
hs 75 lr 8.000000e-04 reg 7.500000e-01 val accuracy: 0.458000
hs 75 lr 8.000000e-04 reg 1.000000e+00 val accuracy: 0.479000
hs 75 lr 8.000000e-04 reg 1.250000e+00 val accuracy: 0.462000
hs 75 lr 9.000000e-04 reg 7.500000e-01 val accuracy: 0.469000
hs 75 lr 9.000000e-04 reg 1.000000e+00 val accuracy: 0.462000
hs 75 lr 9.000000e-04 reg 1.250000e+00 val accuracy: 0.468000
hs 75 lr 1.000000e-03 reg 7.500000e-01 val accuracy: 0.487000
hs 75 lr 1.000000e-03 reg 1.000000e+00 val accuracy: 0.467000
hs 75 lr 1.000000e-03 reg 1.250000e+00 val accuracy: 0.470000
hs 75 lr 1.100000e-03 reg 7.500000e-01 val accuracy: 0.479000
hs 75 lr 1.100000e-03 reg 1.000000e+00 val accuracy: 0.476000
hs 75 lr 1.100000e-03 reg 1.250000e+00 val accuracy: 0.473000
hs 100 lr 7.000000e-04 reg 7.500000e-01 val accuracy: 0.476000
hs 100 lr 7.000000e-04 reg 1.000000e+00 val accuracy: 0.475000
hs 100 lr 7.000000e-04 reg 1.250000e+00 val accuracy: 0.458000
hs 100 lr 8.000000e-04 reg 7.500000e-01 val accuracy: 0.486000
hs 100 lr 8.000000e-04 reg 1.000000e+00 val accuracy: 0.477000
hs 100 lr 8.000000e-04 reg 1.250000e+00 val accuracy: 0.464000
hs 100 lr 9.000000e-04 reg 7.500000e-01 val accuracy: 0.490000
hs 100 lr 9.000000e-04 reg 1.000000e+00 val accuracy: 0.479000
hs 100 lr 9.000000e-04 reg 1.250000e+00 val accuracy: 0.476000
hs 100 lr 1.000000e-03 reg 7.500000e-01 val accuracy: 0.495000
hs 100 lr 1.000000e-03 reg 1.000000e+00 val accuracy: 0.469000
hs 100 lr 1.000000e-03 reg 1.250000e+00 val accuracy: 0.472000
hs 100 lr 1.100000e-03 reg 7.500000e-01 val accuracy: 0.483000
hs 100 lr 1.100000e-03 reg 1.000000e+00 val accuracy: 0.470000
hs 100 lr 1.100000e-03 reg 1.250000e+00 val accuracy: 0.459000
hs 125 lr 7.000000e-04 reg 7.500000e-01 val accuracy: 0.473000
hs 125 lr 7.000000e-04 reg 1.000000e+00 val accuracy: 0.478000
hs 125 lr 7.000000e-04 reg 1.250000e+00 val accuracy: 0.466000
hs 125 lr 8.000000e-04 reg 7.500000e-01 val accuracy: 0.467000
hs 125 lr 8.000000e-04 reg 1.000000e+00 val accuracy: 0.483000
hs 125 lr 8.000000e-04 reg 1.250000e+00 val accuracy: 0.471000
hs 125 lr 9.000000e-04 reg 7.500000e-01 val accuracy: 0.481000
hs 125 lr 9.000000e-04 reg 1.000000e+00 val accuracy: 0.480000
hs 125 lr 9.000000e-04 reg 1.250000e+00 val accuracy: 0.479000
hs 125 lr 1.000000e-03 reg 7.500000e-01 val accuracy: 0.471000
hs 125 lr 1.000000e-03 reg 1.000000e+00 val accuracy: 0.479000
hs 125 lr 1.000000e-03 reg 1.250000e+00 val accuracy: 0.458000
hs 125 lr 1.100000e-03 reg 7.500000e-01 val accuracy: 0.474000
hs 125 lr 1.100000e-03 reg 1.000000e+00 val accuracy: 0.470000
hs 125 lr 1.100000e-03 reg 1.250000e+00 val accuracy: 0.469000
best validation accuracy achieved during cross-validation: 0.495000
