在使用Spring Cloud Gateway限流功能時官網提供的限流中的流速以及桶容量是針對所有策略的，意思是隻要配置上那麼所有的都是一樣的，不能根據不同的型別配置不同的引數，例如：A渠道、B渠道，若配置上replenishRate（流速）和burstCapacity（令牌桶容量），那麼不管是A渠道還是B渠道都是這個值，如果修改那麼對應的其他渠道也會修改，如何能做到分為不同渠道進行限流呢，A渠道replenishRate：10，burstCapacity：100，B渠道：replenishRate：20，burstCapacity：1000，下面開始分析：
限流方式採用的redis，底層使用的redis的lua指令碼實現的，具體可以自行查閱，不做講解，預設限流類：RedisRateLimiter，本文也是仿照這個進行重寫的。
本文是參考“

引入依賴

<dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-data-redis-reactive</artifactId>
</dependency>

自定義限流類

參照RedisRateLimiter進行自定義限流類SystemRedisRateLimiter用於渠道限流方式，實現程式碼如下：

/**
 * @author : Erick
 * @version : 1.0
 * @Description :
 * @time :2018-12-1
 */
public class SystemRedisRateLimiter extends AbstractRateLimiter<SystemRedisRateLimiter.Config> implements ApplicationContextAware {
	//這些變數全部從RedisRateLimiter複製的，都會用到。
    public static final String REPLENISH_RATE_KEY =

 "replenishRate";

    public static final String BURST_CAPACITY_KEY = "burstCapacity";

    public static final String CONFIGURATION_PROPERTY_NAME = "sys-redis-rate-limiter";
    public static final String REDIS_SCRIPT_NAME = "redisRequestRateLimiterScript";
    public static final String REMAINING_HEADER = "X-RateLimit-Remaining";
    public static final String REPLENISH_RATE_HEADER = "X-RateLimit-Replenish-Rate";
    public static final String BURST_CAPACITY_HEADER = "X-RateLimit-Burst-Capacity";

    //處理速度
    private static final String DEFAULT_REPLENISHRATE="default.replenishRate";
    //容量
    private static final String DEFAULT_BURSTCAPACITY="default.burstCapacity";

    private ReactiveRedisTemplate<String, String> redisTemplate;
    private RedisScript<List<Long>> script;
    private AtomicBoolean initialized = new AtomicBoolean(false);

    private String remainingHeader = REMAINING_HEADER;

    /** The name of the header that returns the replenish rate configuration. */
    private String replenishRateHeader = REPLENISH_RATE_HEADER;

    /** The name of the header that returns the burst capacity configuration. */
    private String burstCapacityHeader = BURST_CAPACITY_HEADER;

    private Config defaultConfig;

    public SystemRedisRateLimiter(ReactiveRedisTemplate<String, String> redisTemplate,
                                  RedisScript<List<Long>> script, Validator validator) {
        super(Config.class , CONFIGURATION_PROPERTY_NAME , validator);
        this.redisTemplate = redisTemplate;
        this.script = script;
        initialized.compareAndSet(false,true);
    }

    public SystemRedisRateLimiter(int defaultReplenishRate, int defaultBurstCapacity){
        super(Config.class , CONFIGURATION_PROPERTY_NAME , null);
        defaultConfig = new Config()
                .setReplenishRate(defaultReplenishRate)
                .setBurstCapacity(defaultBurstCapacity);

    }
	//具體限流實現，此處呼叫的是lua指令碼
    @Override
    public Mono<RateLimiter.Response> isAllowed(String routeId, String id) {
        if (!this.initialized.get()) {
            throw new IllegalStateException("RedisRateLimiter is not initialized");
        }
        if (ObjectUtils.isEmpty(rateLimiterConf) ){
            throw new IllegalArgumentException("No Configuration found for route " + routeId);
        }
        //獲取的是自定義的map
        Map<String , Integer> rateLimitMap = rateLimiterConf.getRateLimitMap();
        //快取的key
        String replenishRateKey = routeId + "." + id + "." + REPLENISH_RATE_KEY;
		//若map中不存在則採用預設值，存在則取值。
        int replenishRate = ObjectUtils.isEmpty(rateLimitMap.get(replenishRateKey)) ? rateLimitMap.get(DEFAULT_REPLENISHRATE) : rateLimitMap.get(replenishRateKey);
        //容量key
        String burstCapacityKey = routeId + "." + id + "." + BURST_CAPACITY_KEY;
		//若map中不存在則採用預設值，存在則取值。
        int burstCapacity = ObjectUtils.isEmpty(rateLimitMap.get(burstCapacityKey)) ? rateLimitMap.get(DEFAULT_BURSTCAPACITY) : rateLimitMap.get(burstCapacityKey);

        try {
            List<String> keys = getKeys(id);

            List<String> scriptArgs = Arrays.asList(replenishRate + "", burstCapacity + "",
                    Instant.now().getEpochSecond() + "", "1");
            Flux<List<Long>> flux = this.redisTemplate.execute(this.script, keys, scriptArgs);

            return flux.onErrorResume(throwable -> Flux.just(Arrays.asList(1L, -1L)))
                    .reduce(new ArrayList<Long>(), (longs, l) -> {
                        longs.addAll(l);
                        return longs;
                    }) .map(results -> {
                        boolean allowed = results.get(0) == 1L;
                        Long tokensLeft = results.get(1);

                        RateLimiter.Response response = new RateLimiter.Response(allowed, getHeaders(replenishRate , burstCapacity , tokensLeft));

                        return response;
                    });
        } catch (Exception e) {
            e.printStackTrace();
        }

        return Mono.just(new RateLimiter.Response(true, getHeaders(replenishRate , burstCapacity , -1L)));
    }

    private RateLimiterConf rateLimiterConf;
    @Override
    public void setApplicationContext(ApplicationContext applicationContext) throws BeansException {
        this.rateLimiterConf = applicationContext.getBean(RateLimiterConf.class);
    }

    public HashMap<String, String> getHeaders(Integer replenishRate, Integer burstCapacity , Long tokensLeft) {
        HashMap<String, String> headers = new HashMap<>();
        headers.put(this.remainingHeader, tokensLeft.toString());
        headers.put(this.replenishRateHeader, String.valueOf(replenishRate));
        headers.put(this.burstCapacityHeader, String.valueOf(burstCapacity));
        return headers;
    }

    static List<String> getKeys(String id) {
        // use `{}` around keys to use Redis Key hash tags
        // this allows for using redis cluster

        // Make a unique key per user.
        //此處可以自定義redis字首資訊
        String prefix = "request_sys_rate_limiter.{" + id;

        // You need two Redis keys for Token Bucket.
        String tokenKey = prefix + "}.tokens";
        String timestampKey = prefix + "}.timestamp";
        return Arrays.asList(tokenKey, timestampKey);
    }


    @Validated
    public static class Config{
        @Min(1)
        private int replenishRate;
        @Min(1)
        private int burstCapacity = 1;

        public int getReplenishRate() {
            return replenishRate;
        }

        public Config setReplenishRate(int replenishRate) {
            this.replenishRate = replenishRate;
            return this;
        }

        public int getBurstCapacity() {
            return burstCapacity;
        }

        public Config setBurstCapacity(int burstCapacity) {
            this.burstCapacity = burstCapacity;
            return this;
        }

        @Override
        public String toString() {
            return "Config{" +
                    "replenishRate=" + replenishRate +
                    ", burstCapacity=" + burstCapacity +
                    '}';
        }
    }
}

在繼承AbstractRateLimiter泛型使用的是自定義類中的config：SystemRedisRateLimiter.Config

配置類

配置類主要用於初始化map引數。

/**
 * @author : Erick
 * @version : 1.0
 * @Description :
 * @time :2018-12-1
 */
@Component
//使用配置檔案的方式進行初始化
@ConfigurationProperties(prefix = "ratelimiter-conf")
public class RateLimiterConf {
    //處理速度
    private static final String DEFAULT_REPLENISHRATE="default.replenishRate";
    //容量
    private static final String DEFAULT_BURSTCAPACITY="default.burstCapacity";

    private Map<String , Integer> rateLimitMap = new ConcurrentHashMap<String , Integer>(){
        {
            put(DEFAULT_REPLENISHRATE , 10);
            put(DEFAULT_BURSTCAPACITY , 100);
        }
    };

    public Map<String, Integer> getRateLimitMap() {
        return rateLimitMap;
    }

    public void setRateLimitMap(Map<String, Integer> rateLimitMap) {
        this.rateLimitMap = rateLimitMap;
    }
}

配置檔案主要採用配置檔案的方式進行初始化，若配置則進行新增，若沒有配置則採用預設值。

配置檔案

主要用於配置各個渠道的限流閥值，例如文章開頭舉例的A渠道和B渠道，配置如下：

//與配置類RateLimiterConf保持一致
ratelimiter-conf:
  #配置限流引數與RateLimiterConf類對映
  rateLimitMap:
    #格式為：routeid(gateway配置routes時指定的).系統名稱.replenishRate(流速)/burstCapacity令牌桶大小
    service.A.replenishRate: 10
    service.A.burstCapacity: 100
    service.B.replenishRate: 20
    service.B.burstCapacity: 1000

到此配置限流相關的程式碼已經完成，需要在啟動類和bootstrap.yml中進行配置才能夠真正的使用。

啟動類中聲名

在啟動類中宣告使用的策略，指定自定義限流類。

@Bean
 KeyResolver sysKeyResolver(){
 	  //從請求地址中擷取sys值，進行限流。
     return exchange -> Mono.just(exchange.getRequest().getQueryParams().getFirst("sys"));
 }

@Bean
@Primary
//使用自己定義的限流類
SystemRedisRateLimiter systemRedisRateLimiter(
        ReactiveRedisTemplate<String, String> redisTemplate,
        @Qualifier(SystemRedisRateLimiter.REDIS_SCRIPT_NAME) RedisScript<List<Long>> script,
        Validator validator){
    return new SystemRedisRateLimiter(redisTemplate , script , validator);
}

採用的是從請求地址中獲取sys引數對應的值，當然也可以設定為其他值，再聲名自定義的限流類。

配置限流

spring:
  cloud:
    gateway:
      routes:
        - id: service //id名稱需要與配置限流的保持一致
          uri: lb://serviceA
          predicates:
            - Path=/service/**/ //最後的/可以去掉，在本文中特意新增的如果去掉會把filters當成註釋內容。
          filters:
            - name: RequestRateLimiter
              args:
                //需要與上邊的方法名保持一致
                rate-limiter: "#{@systemRedisRateLimiter}"
                //需要與策略類的方法名保持一致。
                key-resolver: "#{@sysKeyResolver}"

至此自定義限流程式碼全部完成，如有什麼不妥支援請指正，同時也希望對其他人有幫助。例項程式碼已上傳到碼雲可以點選檢視。
