多種方式實現二維碼
阿新 • • 發佈:2018-11-25
最近和一位前輩學習生成二維碼(Zxing,Qrcode,Jquery)3種方式,整理了一份簡單資料分享給大家。本人編碼閱歷有限,下文程式碼中存在編碼規範問題,還請多多留言。
下文所提到的工具包:雙擊免費工具包下載
提取碼:gm03
Zxing
谷歌推出的一款開源專案。
需要包:
zxing-3.3.2.jar
建立二維碼
package student.com.zxing; import java.io.File; import java.nio.file.Path; import java.util.HashMap; import java.util.UUID; import com.google.zxing.BarcodeFormat; import com.google.zxing.EncodeHintType; import com.google.zxing.MultiFormatWriter; import com.google.zxing.client.j2se.MatrixToImageWriter; import com.google.zxing.common.BitMatrix; import com.google.zxing.qrcode.decoder.ErrorCorrectionLevel; /** * * @author Bad Written * */ public class CreateZxing { /** * * @param content * @param width * @param height * @param charsetName * @return BitMatrix物件(儲存將要生成的二維碼的位元組資料) * @throws Exception */ public static BitMatrix createBitMatrix(String content, int width, int height,String charsetName) throws Exception{ //要生成什麼格式的二維碼 BitMatrix bitMatrix=null; //二維碼當中要儲存什麼資訊 HashMap<EncodeHintType, Comparable> hints = new HashMap<EncodeHintType, Comparable>(); hints.put(EncodeHintType.CHARACTER_SET, charsetName); //設定糾錯率,分為L、M、H三個等級,等級越高,糾錯率越高,但儲存的資訊越少 hints.put(EncodeHintType.ERROR_CORRECTION, ErrorCorrectionLevel.M); //設定一下邊距,預設是5 hints.put(EncodeHintType.MARGIN, 2); bitMatrix = new MultiFormatWriter().encode(content, BarcodeFormat.QR_CODE, width, height, hints); return bitMatrix; } /** * * @param content 內容 * @param format 圖片格式 * @param width 圖片寬 * @param height 高 * @param charsetName 編碼格式 * @param filepath 檔案路徑 * @throws Exception */ public static void create(String content,String format, int width, int height,String charsetName,String filepath) throws Exception{ BitMatrix bitMatrix=CreateZxing.createBitMatrix(content, width, height,charsetName); File file=new File(filepath+File.separator+UUID.randomUUID().toString().replace("-", "")+"."+format); Path path = file.toPath(); MatrixToImageWriter.writeToPath(bitMatrix, format, path); } public static void main(String[] args){ System.out.println("開始"); try{ CreateZxing.create("Zxing生成二維碼!","png",300,300,"utf-8","E:/code"); System.out.println("成功"); }catch(Exception e){ e.printStackTrace(); } } }
生成結果如圖:
讀取二維碼
package study.com.zxing; import java.awt.image.BufferedImage; import java.io.File; import java.io.IOException; import java.util.HashMap; import javax.imageio.ImageIO; import com.google.zxing.BinaryBitmap; import com.google.zxing.EncodeHintType; import com.google.zxing.MultiFormatReader; import com.google.zxing.NotFoundException; import com.google.zxing.Result; import com.google.zxing.client.j2se.BufferedImageLuminanceSource; import com.google.zxing.common.HybridBinarizer; /** * * @author Bad Written * */ public class ReadZxingCode { public static Result read(String filepath,String charsetName) throws IOException, NotFoundException{ Result result=null; MultiFormatReader mfr=new MultiFormatReader(); File file=new File(filepath); BufferedImage img=ImageIO.read(file); BinaryBitmap binaryBitmap=new BinaryBitmap(new HybridBinarizer(new BufferedImageLuminanceSource(img))); HashMap hints = new HashMap(); hints.put(EncodeHintType.CHARACTER_SET,charsetName); result=mfr.decode(binaryBitmap,hints); return result; } public static void main(String[] args){ System.out.println("開始"); Result result; try { result = ReadZxingCode.read("E:/code/d4ebf9c4917f401da607df77ac50a346.png","utf-8"); System.out.println(result.toString()); } catch (NotFoundException e) { e.printStackTrace(); } catch (IOException e) { e.printStackTrace(); } } }
QRcode
包:1.2\qrcode-1.2.jar
建立二維碼
package study.com.qrcode; import java.awt.Color; import java.awt.Graphics2D; import java.awt.image.BufferedImage; import java.io.File; import java.io.IOException; import java.util.UUID; import javax.imageio.ImageIO; import com.swetake.util.Qrcode; /* * 基於Graphics2D畫圖工具 */ public class CreateQRCode { /** * 返回一個圖片快取 * * @param context 圖片內容 * @param size 二維碼版本 * @charsetName 編碼格式 * @return * @throws IOException */ private static BufferedImage createbuf(String context,int size,String charsetName) throws IOException{ //二維碼類 Qrcode qr=new Qrcode(); //糾錯等級 qr.setQrcodeErrorCorrect('M'); //代表其他字元 qr.setQrcodeEncodeMode('B'); //設定設定二維碼尺寸,取值範圍1-40,值越大尺寸越大,可儲存的資訊越大 qr.setQrcodeVersion(size); //二維碼大小 int width=67+12*(size-1);//公式 int height=67+12*(size-1); //緩衝區圖片 BufferedImage bufimg=new BufferedImage(width, height, BufferedImage.TYPE_INT_RGB); //畫圖工具 Graphics2D gs=bufimg.createGraphics(); gs.setBackground(Color.WHITE); gs.setColor(Color.BLACK); //設定畫板 gs.clearRect(0, 0, width, height); //內容編碼 byte[] d=context.getBytes(charsetName); int pixoff=2;//偏移量 // 輸出內容> 二維碼 if(d.length>0 && d.length<120){ boolean[][] s=qr.calQrcode(d); for(int i=0;i<s.length;i++){ for(int j=0;j<s.length;j++){ if(s[j][i]){ gs.fillRect(j*3+pixoff, i*3+pixoff, 3, 3); } } } } gs.dispose(); bufimg.flush(); return bufimg; } /** * * @param context 內容 * @param size 版本 * @param type 圖片格式 * @param imgpath 圖片路徑 * @throws IOException */ public static void create(String context,int size,String type,String imgpath) throws IOException{ BufferedImage bufimg=CreateQRCode.createbuf(context,size,"gb2312"); File file=new File(imgpath+File.separator+UUID.randomUUID().toString().replace("-", "")+"."+type); ImageIO.write(bufimg, type, file); } public static void main(String[] args) { System.out.println("開始"+File.separator); try{ CreateQRCode.create("Qrcode生成二維碼", 7, "png", "E:/code"); System.out.println("成功"); }catch(IOException e){ System.out.println("失敗"); e.printStackTrace(); } } }
生成二維碼如圖:
讀取二維碼
主工具類
package study.com.qrcode;
import java.awt.image.BufferedImage;
import java.io.File;
import java.io.IOException;
import javax.imageio.ImageIO;
import jp.sourceforge.qrcode.QRCodeDecoder;
public class ReadQrCode {
/**
*
* @param filepath 檔案路徑
* @param charsetName 編碼格式
* @return 解析出來結果
* @throws IOException
*/
public static String read(String filepath,String charsetName) throws IOException{
String result=null;
File file=new File(filepath);
BufferedImage img=ImageIO.read(file);
QRCodeDecoder qrCodeDecoder=new QRCodeDecoder();
result=new String(qrCodeDecoder.decode(new QrCodeImgImp(img)),charsetName);
return result;
}
public static void main(String[] args) throws IOException{
String str=ReadQrCode.read("E:/code/qrcode.png","gb2312");
System.out.println("解析:"+str);
}
}
副類
package study.com.qrcode;
import java.awt.image.BufferedImage;
import jp.sourceforge.qrcode.data.QRCodeImage;
public class QrCodeImgImp implements QRCodeImage {
BufferedImage bufimg;
public QrCodeImgImp(BufferedImage bufimg){
this.bufimg=bufimg;
}
public int getHeight() {
// TODO Auto-generated method stub
return bufimg.getHeight();
}
public int getPixel(int arg0, int arg1) {
// TODO Auto-generated method stub
return bufimg.getRGB(arg0, arg1);
}
public int getWidth() {
// TODO Auto-generated method stub
return bufimg.getWidth();
}
}
JQuery
匯入相應的JS
jquery.qrcode.min.js
jquery-3.3.1.min.js
生成二維碼
<%@ page language="java" contentType="text/html; charset=UTF-8"
pageEncoding="UTF-8"%>
<!DOCTYPE html PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN" "http://www.w3.org/TR/html4/loose.dtd">
<html>
<head>
<meta http-equiv="Content-Type" content="text/html; charset=UTF-8">
<title>生成二維碼</title>
</head>
<script type="text/javascript" src="<%=request.getContextPath() %>/js/jquery-3.3.1.min.js"></script>
<script type="text/javascript" src="<%=request.getContextPath() %>/js/jquery.qrcode.min.js"></script>
<script type="text/javascript">
$(document).ready(function() {
$('#qrcode').qrcode(
{
render : "canvas", //設定渲染方式,有table和canvas,使用canvas方式渲染效能相對來說比較好
text : "http://www.baidu.com", //掃描二維碼後顯示的內容,可以直接填一個網址,掃描二維碼後自動跳向該連結
width : "200", //二維碼的寬度
height : "200", //二維碼的高度
background : "#ffffff", //二維碼的後景色
foreground : "#000000", //二維碼的前景色
});
}
)
</script>
<body>
生成二維碼如下
<center>
<div id="qrcode"></div>
</center>
<h3>顯示結束</h3>
</body>
</html>
